NAIM Amplifiers - 17.4 NAC 152 XS Connected to Hi-Cap and FlatCap XS Power Supplies (stage 2 upgrade)

14
NAC 202
to power
amplifier
with internal
power supply
15.2 NAC 202 Rear
in 1
cd
in 2
tuner
in 3
tape
in 4
av
in 5
aux 1
in 6
aux 2
cd/RCA Phono
ch1
ch2
aux 2/RCA Phono
ch1
ch2
RS232
interface
RC5 in
ch1
-ve
nc
nc
ch2
Inputs 1, 2 & 6
ch1
-ve
ch1
(out)
ch2
(out)
ch2
Inputs 3, 4 & 5
+ve
-ve
+ve
ch1
+ve
ch2
Input 6
(alternative)
signal
ground
in 6
(alternative)
Note:
The NAC 202 AUX 2 input is provided with two sockets. The
upper socket, fitted on delivery with a blanking cover, is intended
for use with a Stageline or Prefix RCA Phono stage and incorporates
an appropriate DC power supply. The two sockets must not be used
simultaneously.
Note:
The RS232/comms interface is an optional upgrade. It can
be specified at time of order or fitted retrospectively. Contact your
local representative or Naim Audio directly for further information.
to NAPSC
power supply/output option sockets
with link and blanking plugs fitted
16. NAC 202 Specification
Input Sensitivities:
75mV, 47kΩ
Overload Margins:
40dB
(all inputs all audio frequencies)
Main Output Level:
0.775V, <50Ω
Tape Output Level:
75mV, 600Ω
Auxiliary Power Outputs:
For Stageline/Prefix phono stage.
Dimensions (H x W x D):
NAC 282 - 87 x 432 x 314mm
15.3 NAC 202 Connected to Hi-Cap and NAPSC
mains input
and fuse
to stereo power amplifiers
to mono or dual
mono power
amplifiers
additional
signal
output
cable
direction
marker
240° 5 to 5 pin DIN
Interconnect Cables
