Power Supply
Flatcap 2, NAPSA, NAPSC
51 Installation
Power supplies should be installed in their final location before connecting cables or
switching on. Ensure that power amplifiers are switched off and the preamplifier volume
is turned down before power supplies are switched on.
The Flatcap 2 and NAPSA are heavy and care should be taken when lifting or moving
them. Make sure that the surface on which they are to be placed can support their full
weight.
mains input
and fuse
51.1 Flatcap 2 Rear
socket
1
socket
2
socket
4
socket
3
socket
5
power
switch
socket
6
ch2
ch1
nc
-ve
Inputs 2, 3, 4 & 6
+ve
-ve
+ve
ch1
+ve
ch2
Sockets 1 & 5
mains input and fuse
51.2 NAPSA (Armageddon) Rear
turntable power
output
mains input and fuse
51.3 NAPSC Rear
output lead to
preamplifier or Headline
