Contents
Page
Section
1
1
Equipment Installation
2
Audio Connections
3
Mains Power Connection
2
4
General Installation
3
Preamplifiers
5
NAC 552
Installation and Operation
4
6
NAC 552 Connection Diagrams
5
7
NAC 552 Specification
6
8
NAC 252
Installation and Operation
7
9
NAC 252 Connection Diagrams
8
10
NAC 252 Specification
9
11
NAC 282
Installation and Operation
10
12
NAC 282 Connection Diagrams
11
13
NAC 282 Specification
12
14
NAC 202
Installation and Operation
13
15
NAC 202 Connection Diagrams
14
16
NAC 202 Specification
15
17
NAC 112x
Installation and Operation
NAC 112x Installation and OperationNAC 112x
16
18
NAC 112x Connection Diagrams
17
19
NAC 112x Specification
18
Integrated Amplifier
20
NAIT 5i
Installation and Operation
19
21
NAIT 5i Connection Diagrams
22
NAIT 5i Specification
20
Remote Handsets
23
Flash
Remote Handset
21
24
NARCOM 3
Remote Handset
23
25
iCom
Remote Handset
24
Power Amplifiers
26
NAP 500
Installation and Operation
25
27
NAP 500 Connection Diagram
28
NAP 500 Specification
26
29
NAP 300
Installation and Operation
27
30
NAP 300 Connection Diagram
31
NAP 300 Specification
28
32
NAP 250
Installation and Operation
33
NAP 250 Connection Diagram
34
NAP 250 Specification
29
35
NAPV 145
Installation and Operation
36
NAV 145 Connection Diagram
37
NAV 145 Specification
30
38
NAP 200
Installation and Operation
39
NAP 200 Connection Diagram
40
NAP 200 Specification
31
41
NAP 150x
Installation and Operation
42
NAP 150x Connection Diagram
43
NAP 150x Specification
32
44
NAPV 175
Installation and Operation
45
NAPV 175 Connection Diagram
46
NAPV 175 Specification
33
47
NAP 6-50
Installation and Operation
48
NAP 6-50 Connection Diagram
49
NAP 6-50 Specification
34
Power Supplies
50
Supercap, XPS, Hi-Cap
Installation and Connection
35
51
Flatcap 2, NAPSA, NAPSC
Installation and Connection
36
52
Power Supply Specifications
53
Declaration of Conformity
IMPORTANT
In order to comply with current European safety regulations
it is essential that the Naim loudspeaker connectors supplied
with amplifiers and loudspeakers are used.
Do not under any circumstances allow anyone to modify your
Naim equipment without first checking with the factory, your
dealer, or your distributor. Unauthorised modifications will
invalidate your guarantee.
For your own safety do not under any circumstances open
Naim equipment without first disconnecting it from the
mains.
Warning: an apparatus with CLASS I construction shall be
connected to a mains socket outlet with a protective earthing
connection.
Where the mains plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable. To disconnect the equipment from the mains
remove the mains plug from the mains outlet.
The following label is attached to all mains powered
equipment:
NOTE
This equipment has been tested and found to comply with the
relevant EMC and Safety Standards, and, where applicable,
also complies with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult your Naim dealer or an experienced radio/TV
technician for help.
W A R N I N G
THIS APPARATUS
MUST BE EARTHED
