NAIM NAC 552 - NAC 252 Connections and Controls; NAC 252 Rear Panel Connections; NAC 252 Connected to SuperCap

E7
aux 1
in/out
aux 2
in
cd
in
tuner
in
hdd in/
out
av
in/out
aux 2 in
(alternative)
signal
ground
NAC 252
8 NAC 252 Connections and Controls
8.1 NAC 252 Rear Panel Connections
cd/RCA Phono
ch1(L)
ch2(R)
aux 2/RCA Phono
ch1(L)
ch2(R)
RS232
interface
RC5 in
SuperCapSuperCap
Note: The RS232 interface is an optional upgrade. It can be
specified at time of order or fitted retrospectively. Contact your
local distributor or Naim Audio directly for further information.
ch1
-ve
nc
nc
ch2
cd, tuner and aux
2 inputs
ch1
-ve
ch1
(out)
ch2
(out)
ch2
hdd, av and aux 1
inputs
+ve
-ve
+ve
ch1
ch2
aux 2
(alt.) input
8.2 NAC 252 Connected to SuperCap
mains input
and fuse
Note: For best performance the Burndy and 5 pin DIN cables
should be run as close together as possible.
to stereo power
ampliers
to mono or dual mono power
ampliers
additional signal output
cable
direction
marker
NAC 252 Burndy
240° 5 to 5 pin DIN
Interconnect Cables
