NAIM NAC 552 - NAC 202 Rear Panel Sockets; NAC 152 XS Rear Panel Sockets

E12
cd
in
tuner
in
hdd in/
out
av
in/out
aux 1
in/out
aux 2 in
signal ground aux 2 in
(alternative)
NAC 282, NAC 202 & NAC 152 XS
to power
amplier
with
internal
power
supply
11.2 NAC 202 Rear Panel Sockets
11.3 NAC 152 XS Rear Panel Sockets
cd/RCA Phono
ch1(L)
ch2(R)
aux 2/RCA
Phono
ch1(L)
ch2(R)
RS232
interface
RC5 in
Note: The NAC 202 Aux 2 input is provided with two sockets.
The upper socket, fitted on delivery with a blanking cover, is
intended for use with a Stageline or SuperLine Phono stage and
incorporates an appropriate DC power supply. The two sockets
must not be used simultaneously.
Note: The RS232 interface is an optional upgrade. It can be
specified at time of order or fitted retrospectively. Contact
your local representative or Naim Audio directly for further
information.
to NAPSC
power supply/output option sockets
with link and blanking plugs tted
ch1
-ve
nc
nc
ch2
cd, tuner and aux
2 inputs
ch1
-ve
ch1
(out)
ch2
(out)
ch2
hdd, av and aux 1
inputs
+ve
-ve
+ve
ch1
ch2
aux 2
(alt.) input
to power amplier with internal power supply
ch1
-ve
nc
nc
ch2
cd, tun, hdd, av,
and aux inputs
+ve
-ve
+ve
ch1
ch2
aux 2
(alt.) input
Note: The NAC 152 XS Aux 2 input is provided with two sockets.
The right hand socket (fitted on delivery with a blanking cover),
is intended for use with a Stageline or SuperLine phono stage
and incorporates an appropriate DC power supply. The two
sockets must not be used simultaneously.
Note: The RS232 interface is an optional upgrade. It can be
specified at time of order or fitted retrospectively. Contact
your local representative or Naim Audio directly for further
information.
signal ground
cd
in
tuner
in
hdd
in
aux 1
in
av
in
aux 2 in
(alternative)
power supply upgrade
link plugs tted
remote in
RS232
interface
to power amplier with
internal power supply
aux 2
in
cd in
phono
tuner in
phono
hdd in
phono
av in
phono
aux 1 in
phono
line
output
subwoofer
output
Note: The NAC 152 XS features various technologies to reduce
microphonic effects, consequently some movement sockets when
connecting and disconnecting cables is normal.
Note: The NAC 202 features various technologies to reduce
microphonic effects, consequently some movement sockets when
connecting and disconnecting cables is normal.
