Trial OperationFP0
9-3Matsushita Automation Controls
9.1 Before Turning ON the Power
9.1 Before Turning ON the Power
After wiring, be sure to check the items below before turning ON the power supply to
the programmable controller.
Item Description
Unit mounting status
S
Does the unit type match the device list during the design
stage?
S
Are all of the units firmly fixed?
Power supply
S
Is operating voltage supplied correctly ?
S
Is the power supply cable properly connected?
Check input/output
terminals
S
Does the wiring of connector and terminal match ?
S
Is the operating voltage of I/O correct ?
S
Are the connector of I/O properly connected ?
S
Is the wire size correct ?
Setting of control unit
S
Is the mode switch set to the PROG. mode ?
