I/O
Allocation
FP0
5-4
Matsushita
Automation
Controls
5.2
Control
Unit
5.2
Control
Unit
The
I/O
allocation
of
the
FP0
control
unit
is
fixed.
T
ype
I/O
number
C10RS,
C10CRS,
C10RM,
C10CRM
Input:
6
points
X0
to
X5
,
,
,
Output:
4
points
Y0
to
Y3
C14RS,
C14CRS,
C14RM,
C14CRM
Input:
8
points
X0
to
X7
,
,
,
Output:
6
points
Y0
to
Y5
C16T
,
C16CT
,
C16P
,
C16CP
Input:
8
points
X0
to
X7
,
,
,
Output:
8
points
Y0
to
Y7
C32T
,
C32CT
,
C32P
,
C32CP
Input:
16
points
X0
to
XF
,
,
,
Output:
16
points
Y0
to
YF
97
99
