NAMCO LUCKY & WILD User Manual

54 Test Screens
1. Switch Test Screen
_ _. __ _ __ _ _
(a) DIP SW
This test displays the status of the option switches on the game PC board
(CPU-PCS). Any number displayed in RED. indicates it is turned ‘ON’.
(b) TEST SW
(c) COIN 1 SW
If ‘ON’ is displayed in RED, the condiiion is normal.
‘ON’ is displayed in RED when the coin 1 switch is wnec ‘ON’. and the
numbers will advance. (The coin meter will not advance)
(d) COIN 2 SW
(e) HANDLE
(Steering)
Not used.
If the following v&es are displayed when the steering wheel is operated. the
condition is normal.
* With hands off the steering wheel, ‘00 CENTER’ is displayed.
-With the steering wheel turned to the lefi, ‘LEFT OK’ is displayed
and the numbers decrease.
-With the steering wheel turned to the right, ‘RIGHT OK’ is displayed
and the numbers increase.
[f) ACCEL
When the a~cslerat~~ pedal is depressed. the value increases and ‘OK’ is
displayed.
ed.
:g) BRAKE
When the brake pedal is depressed. the value increases and ‘OK is display,
:h) 1 P (LEFt-) GUN
This test is used to test the gun volume and swkch.
If the values change as follows. the condition is normal.
- Move left or right...‘)(’ value changes.
. Move up or down...Y’ value changes.
* Pull the trigger...‘ON” is displayed.
h) 2 P (RIGHT) GUN
. Move left or right...%” value changes.
. Move up or down...‘\l’ value changes.
-Pull the trigger...‘ON’ is displayed.
Dlustration 5-5, SWITCH ~l’t;ST~I’Ai3L~
2. Gun Initialization Screen. (Ref. 5-5)
3. Cross Hatch Pattern Screen. (Ref. 5-7)
4. Cross Hatch Pattern Screen with White Block Adjustment. (Ref. 5-7)
5. Color Bar Test Screen. (Ref. 5-7)
8
