2.6 Testing the Printer
Run this test to check the printer. The test prints and cuts a resident test ticket. Verify this ticket to
judge the printing quality.
Figure 9: Status Ticket
To print the test ticket, power-on the printer while pressing and holding the Paper Feed Button for
approximately 5 seconds. A test ticket similar to above will be printed approximately 3 seconds
after. Press the paper feed button once more and the ticket will feed. Pressing the button again
will result in blank tickets.
Model: PAYCHECK HSC
Firmware: HSC-3.58Z (0xD5F7)
*
Protocol: ITHACA 950
COMMUNICATION
Interface: Serial
Baud: 9600
Data Bits: 8
Parity: NONE
Handshaking: PRT+XON+RTS
Print Mode: Line
PRINT CONTROL
Print Method: No HPQ
Speed: 200 mm/sec
Black Bar Index: Right
No HPQ Burn Time: 275 us
Clear After Cut: 254 steps
Cutter PWM: 80 %
Motor Current: 3
Real Time Command: Disabled
Validation Bit: After Barcode
Cut Cal. (Auto): 161+258 steps
PRINTER ENVIRONMENT CONDITIONS
Voltage: 24.4 Volts
Temperature: 20 Celsius
SYSTEM RESOURCES
FLASH: Used=00000 RAM: Used=00000
Free=65535 Free=65535
LIBRARY INVENTORY (HSC)
Templates: 0,1,2,3,4,5,6,7,8,9,A,B,D,
E,F
Regions: 1,2,3,4,5,6,7,8,h,9,A,B,C,
D,E,F,G,I,J,K,L,N,O,P,Q,R,
S,T,U,Z,X,a,b,c,d,e,f,g,i,
j,k,l,m,n,o,p,q,r,s,t,u,v,
w,x,y,z
Fonts: 0,1,2,3,4,5,7,8,9,A,B,E,P
Graphics:
MANUFACTURING INFORMATION
Printer ID: PC00014
Date Code: 20080623
A to D: 03cc,01e6,01f8,03ce
* S | 0 | HSC-3.58Z | @ | @ | @ | H | @ | P | *
* Indicates the Firmware CRC *
