been selected as an Exit/Entry Follower Zone,
Home/Away with Delay Zones, or 24 Hour Zone.
A8 + User 1 Code - User Program
Mode
A9 Keypad Sleep Mode ON/OFF
Enter this command to turn the keypad sounder
ON/OFF. When the keypad is in Sleep mode all
keypad sounds will be silenced except for key-
pad feedback beeps and Keypad Sounder on
Alarm.
User Commands - Optional
A0 Easy Exit
If enabled in Dealer programming, enter this
command while the panel is Armed to allow 3
minutes to exit the premises through Exit/Entry
and Exit/Entry Follower Zones.
A3 Access on PGM
If enabled in Dealer programming, enter this
command to activate the PGM output (Terminal
15) for 5 seconds.
Dealer Commands
A6 Download
(Programming Required)
Establish a connection between the PCD phone
line and the Control Panel phone line. When
ready, tell the installer to arm, then disarm.
Then enter
A6 in order to establish a
connection. Phone connection to installer will
go "dead" as downloader and panel connect.
A7 Fault Find ON/OFF
Hardwired Zone Operation
Enter this command to turn Fault Find ON/OFF.
While in Fault Find mode, the loop response for
all zones will be set to the faster response of 40
ms. The keypad will beep for .25-seconds when
hardwired zones are faulted and for 1-second
when zones are restored.
Wireless Operation
(Signal Strength)
While in Fault Find mode the keypad will provide
an audible (Table 6) and visual (Figure 5) indi-
cation of each transmitter's signal strength. The
signal strength metering is based on a scale of 4
to 10, with 4 being marginal and 10 being excel-
lent.
The keypad will beep out a number, from 1-4,
corresponding to the signal strength of the trans-
mitter. See Table 6. Each beep is 1-second
long. The keypad will sound a short beep for
transmitters with signal strengths of 3 or less.
Signal Strength Logging Mode
The Signal Strength Logging Mode is a trouble-
shooting tool which allows the collection of sig-
nal strength information for all transmitters on
the system. Normally the Signal Strength of Su-
pervisory Signals are not logged; during Signal
Strength Logging Mode the signal strength infor-
mation for all supervisory signals received over
a two hour period will be saved to the LOG.
Local Activation
Enable [92-4=ON], this will initiate a two hour
test period where all supervisory signals will log
signal strength information.
Signal Strength = 8-10
Signal Strength = 6-7
Signal Strength = 4
Signal Strength = 5
1
1 2
1 2 3
1 2 3 4
FIGURE 5 VISUAL SIGNAL STRENGTH INDICATION
TABLE 6 AUDIBLE SIGNAL STRENGTH INDICATION
SIGNAL STRENGTH KEYPAD SOUNDER
3 or less
.25s BEEP
4
BEEP
5
BEEP BEEP
6-7
BEEP BEEP BEEP
8-10
BEEP BEEP BEEP BEEP
