25
Troubleshooting
1. The bell output drops to about 3
volts in alarm.
The battery/bell circuit is protected by
a PC board trace that may have
burned open by reversal of the battery
leads. It is located on the back of the
PC board just adjacent to the red &
black battery leads. Send in for
service if this occurs.
2. How do I remove the Keypad
Sounder on Alarm?
The keypad sounder follows the Burg
Output. If you need to remove the
Keypad Sounder, then you must
remove the Burg Output from that
zone.
3. How do I activate Chime by Zone?
The Chime feature will automatically
be assigned to all zones, except for
the following:
Zones programmed as Home/Away
with Delay Zones programmed as
Exit/Entry Followers.
Zones programmed for 24 Hour
Protection. To Activate/Deactivate
the chime mode, Press
A5.
4. When using a piezo on the Bell
Output, it constantly buzzes.
This is because there is a constant
loop current flowing through the Bell
circuit for supervision. To eliminate
this, cut resistor R26 which is located
directly above Terminal 9 just below
the heat sink.
5. Where are the fuses?
The control panel incorporates
advanced circuitry which automatically
limits the current when an over current
condition exists without the use of
traditional fuses. The circuit will
restore automatically when the over
current condition is corrected.
6. The PGM Output Pulses in Alarm.
When the PGM lug of the control
panel is programmed for an Armed
indication, it also incorporates an
Alarm Memory function which will
indicate that the system is in an Alarm
condition. If this output is being used
to trigger a long range radio, it can be
converted to a steady output with the
use of a capacitor, negative to PGM
Terminal 15, Pos to Aux. Pwr. Term
12. (220 mF Electrolytic Capacitor, 25
Volts. Increase to 470 mF if
necessary).
7. I short out the bell and the system
does not indicate Bell Trouble.
The Bell Supervision circuit is only
designed to detect a "Bell Cut"; it does
not supervise for a short on the Bell.
8. How do I remove Keypad Sounder
on Alarm?
The keypad sounder follows the Burg
Output. If you need to remove the
Keypad Sounder, then you must
remove the Burg Output from that
zone.
