7
Burglary Zone Wiring
NAPCO's EZ Zone Doubling
TM
is simple. Each
terminal has 2 zones, use an E (2.2 K) type
Zone Doubling Resistor for the primary zone
and a Z (3.9 K) type Zone Doubling Resistor for
the secondary zone.
Wire zones as shown in the wiring diagram (pg.
27). All resistors must be installed, even if the
zone is not used. If required, unsupervised
open circuit devices may be used instead of
closed circuit devices. Program the zone as an
Open Circuit Zone [06] (Zone Doubling Resistor
required). If necessary, use the voltage chart
below to verify proper voltages.
Fire Zone Wiring
Wire the Fire Zone as shown in the Wiring Dia-
gram in the back of this manual. An EOL resis-
tor must
be installed, even if the Fire Zone is not
used. In UL installations, use a UL Listed
NAPCO EOL 2.2K resistor.
PGM Wiring
The PGM is a switched negative output that is
activated depending on the programming option
(s) that have been selected [08], [23] - [25].
Connect the device controlled by the PGM be-
tween +PWR and the PGM terminal (maximum
load of 50 mA).
Keypad Operation
Keypad zone LED's indicate zone status.
ARMED, STATUS and
H SYSTEM LED's pro-
vide system status. The keypad sounder pro-
vides feedback beeps for correct and incorrect
entries.
Keypad Sounder
3 QUICK BEEPS
Panel Armed (System ON)
Chime ON
Fault Find Mode ON
Keypad Sounder ON
Zone Bypassed
6 QUICK BEEPS
Panel Disarmed (System OFF)
Chime OFF
Fault Find Mode OFF
Keypad Sounder OFF
Zone Un-Bypassed
1 SECOND - STEADY TONE
Incorrect Code Entered
Invalid key entry
4 LONG BEEPS (PRIORITY CONDITION)
1. Entering an Arm Code with a faulted zone
(Not an Auto-Bypass Reentry Zone).
2. Entering an Arm Code when the Bell or
PGM is ON (Bell and PGM will turn OFF).
3. Arming with the Fire LED ON - reset re-
quired. Press the
C key.
Terminals 2.2 K Primary 3.9 K Secondary
3&4 Zone 1 Zone 4
5&4 Zone 2 Zone 5
6&7 Zone 3 Zone 6
TABLE 2 EZ ZONE DOUBLING™
Fire Zone Normal 13.0V
Fire Trouble 13.8V
Fire 0.0 V
TABLE 4 VOLTAGE AT FIRE ZONE (Terminals 8 & 9)
Primary (2.2K) and Secondary (3.9K) zones normal 1.9 V
Secondary (3.9K) open 2.5 V
Primary (2.2K) open 3.2 V
Primary (2.2K) and Secondary (3.9K) open 5.0 V
Primary (2.2K) and/or Secondary (3.9K) shorted (Sys. Trbl 7-Zone Trbl) 0.0 V
TABLE 3 VOLTAGE AT TERMINALS 3&4, 5&4, 6&7
