WI850D GEM-P800 Installation Instructions
2
General Information
The GEMINI GEM-P800 control panel provides up to
6 hardwired/wireless zones, a 2-wire fire zone and 2
wireless only zones. Up to eight 4-digit user codes
can be programmed. Ambush, when selected, uses
User 8 code as an Ambush code.
The GEM-P800 is wireless ready. When used with a
GEM-RECV-XP8 receiver, the control panel can sup-
port up to 8 wireless zones, 4 wireless smoke detec-
tors and 4 Keyfobs.
The GEM-RP8 keypad provides complete control of
the GEM-P800 control panel. Information on system
status, bypassed zones, system troubles etc. can be
viewed at the keypad.
The control panel can be easily and quickly pro-
grammed from the keypad. The panel can also be
locally or remotely downloaded using PCD3000 soft-
ware and a PCI 2000/3000 interface or PCL2000A
local Download cable. See Downloading Section
(page 5) for more information.
GEM-P800 Features
Control Panel
•
8 Zones (6 Hardwired/Wireless + 2 wireless)
• 2-wire Fire Zone
• 3 Keypad Panics
• Wireless Ready
• Bell Supervision
• Line Cut Detection
• Answering Machine Override (Second Call)
• 50 Event Log
Communicator
•
2 Telephone Numbers
• Backup Reporting
• Pager Format
• Point ID Format
• Individually Report 8 Users
• Opening after Alarm Report (Cancel Code)
• Conditional Closing Report
For Technical Assistance, Contact the NAPCO Toll Free Helpline 
(800) 645-9440
NAPCO Security Technologies, Inc.
333 Bayview Avenue, Amityville, New York 11701
For Sales and Repairs, call Toll Free: (800) 645-9445
Table of Contents
General Information ...............................................2
GEM-P800 Features .............................................2
Specifications ........................................................3
UL Compatible Smoke Detectors ..........................4
Listings and Approvals ..........................................4
Ordering Information .............................................4
Optional Accessories .............................................4
Programming the Panel .........................................5
Installation .............................................................6
Wiring ....................................................................6
Keypad Operation .................................................7
Panel Operation ....................................................8
Bypassing .............................................................9
User Program Mode ..............................................9
GEM-P800 Commands .......................................10
Dealer Commands .............................................11
Wireless Operation (Signal Strength) ................11
Zone Features .....................................................12
System Times ......................................................13
System Features .................................................14
Telephone Number 1 Programming ....................15
Backup Telephone Programming ........................16
Pager Programming ............................................17
Telephone Number 3 Programming ....................18
Report Codes ......................................................18
Enhanced Communicator Features .....................19
Wireless ..............................................................19
Downloading ........................................................20
Dealer Programming ...........................................21
System Troubles .................................................23
Troubleshooting ...................................................25
Wiring Diagram ....................................................27
Warranty ..............................................................28
