NAPCO Gemini GEM-P3200 Installation Instructions

L NAPCO Security Systems
X GEM-P3200 Installation Instructions
WI817F 10/05

Page 59
KEYPAD CONFIGURATION MODE
Press Abutton
Enter Factory Code:
11123
Configure:
• Keypad Beep ON/OFF
• Entry Sounder
• Keypad Address 01
• New Compat# 0000 **
• EZM Address 00
• Zone Response 00
• Program Control Message# 1
Press Cbutton
(“01 OUT OF SYSTEM”)
Return Jumper JP5 * from Pins 2-3 to Pins 1-2
(“SYSTEM READY”)
Move Jumper JP5 * from Pins 1-2 to Pins 2-3
(Wait about 15 seconds: “01 OUT OF SYSTEM”)
* JP5 is located at the top-right corner of the circuit board.
** If a Compatibility Number other than “0000” is programmed, “OLD COMPAT# XXXX” is displayed.
KEYPAD PROGRAMMING MODES
GEM-RP1CAe2/GEM-K1CA
KEYPADS
Configure:
• Keypad Address (Jumpers J1-J3)
• TouchPad Backlight (Jumper A)
• LCD Backlight (Jumper B)
• Entry Sounder (Jumper C)
GEM-RP2ASe2
KEYPADS
12
4
3
56
7890
A
B
C
D
E
F
G
NEXT/YES
PRIOR/NO
A
RE
A
Scroll Down
Scroll Up
Exit
Yes
No
R
For "K Series" Keypads
Save
Scroll
12
4
3
56
7890
A
B
C
D
E
F
G
NEXT/YES
PRIOR/NO
A
RE
A
Scroll Down
Scroll Up
Exit
Yes
No
For "Classic" Keypads
Save
Scroll
