L NAPCO Security Systems
X GEM-P3200 Installation Instructions
WI817F 10/05
Page 9
SUMMARY OF UL REQUIREMENTS
Residential
Recognized Limited-Energy Cable for initiating, indicating and supplementary circuits.
Initiating loops supervised if longer than 3 feet
FT2200 End-of-Line Relay for Fire (if using 4-wire smoke detectors)
Minimum alarm timeout of 5 minutes
Maximum exit time: 60 seconds
Maximum entry time: 45 seconds
Do not program “Swinger Shutdown”, “Force (Auto) Arming”, “Selective Bypass”, “Group (Interior) Bypass”,
“50ms Loop Response”, "20ms Loop Response", or "Auto Bypass"
“Abort Delay” may not exceed 45 seconds
Program “Disable Callback Download”
Automatic dialer may not dial a police station number that has not been dedicated for such service
System must be tested at least weekly under AC/battery and Battery-Only conditions
Replace the rechargeable battery at least every 5 years
If the battery is heavily discharged, replace it or have it tested by a qualified technician
For silent panic, connect only to UL-listed holdup devices
All zones must be programmed for “Priority”
Do not program any zones for “Keyswitch Arming”
System must be serviced at least once every year
Residential Fire and Combination Residential Fire & Burglary must program “Residential Fire”
Keypad Expansion (EZM) Zones are not to be used as fire zones
Compatible Smoke Detectors
2 Wire Smoke Detectors
Manufacturer Model Base
NAPCO FW-2 N/A
Sentrol/ESL 711U, 712U, 701U, 702U,
721U, 721UT, 702RE, 702RU
722U, 731U, 732U
System Sensor 1100, 1151, N/A
1400, 2100, N/A
2100T, 2100S, N/A
2100TS, 2151, N/A
2400, 2400TH N/A
Note: Voltage Rating: 8.5–13.3 VDC
Maximum Number of Detectors: 10
4 Wire Smoke Detectors
Manufacturer Model Base
Gentex 812, 812T, 812P, N/A
812PT, 812PH, N/A
8120, 8120T, N/A
8120P, N/A
8120PTY, 8120-PH N/A
Hochiki SLG-12 w/YBC-RL4-RA base N/A
NAPCO FW-4 N/A
Sentrol/ESL 445AT, 445C, N/A
445CT, 445CR, N/A
445CRT N/A
System Sensor 1112, 2112, N/A
21112T, 211TSRB N/A
1412TH, 2412TH N/A
2312/24T, 1412, N/A
Note: Subtract total smoke-detector alarm current
from available standby current.
UL Compatible Smoke Detectors (Providing UL Recognition or Listing)
Note: Any normally-open devices that do not require power from the control panel may be used (such as
pull stations, waterflow and thermostats), if acceptable to the authority having jurisdiction.
