Napoleon ALLURAVISION Series User Manual

W415-2212 / G / 02.10.20
EN
4
table of contents
1.0 dimensions 5
2.0 general information 6
2.1 listing approvals 6
2.2 general instructions 6
2.3 rating plate information 7
2.4 hardware list 7
2.5 label location 8
3.0 location 9
3.1 unpacking and testing the appliance 9
3.2 grounding the appliance 9
4.0 installation 10
4.1 minimum clearance to combustibles 10
4.2 minimum mantel clearances 10
4.3 installing the appliance onto the wall 11
4.4 recessing the appliance into the wall 13
4.4.1 trim installation (recessed installation only) 14
4.4.2 installing the appliance into a mantel 15
4.5 120V hard wiring installation 16
4.5.1 NEFL42 / 50 / 60 / 74 CHS 120V hardwiring 16
4.5.2 NEFL42 / 50 / 60 / 74 CHD 120V hardwiring 17
4.6 240V hard wiring installation (NEFL42 / 50 / 60 / 74 / 100 CHD only) 18
5.0 framing - recessed installation 20
6.0 finishing 21
6.1 crystal ember installation 21
6.2 optional topaz glass chips and drift wood log installation 21
6.3 front glass installation and removal 22
7.0 wiring diagram 23
7.1 NEFL42 / 50 / 60 / 74 CHS wiring diagram 23
7.2 NEFL42 / 50 / 60 / 74 / 100 CHD wiring diagram 24
8.0 operation 25
8.1 operating control panel 25
8.2 operating remote control 26
9.0 maintenance 27
9.1 remote battery installation 27
10.0 replacement parts 28
10.1 NEFL42 / 50 / 60 / 74 CHS 29
10.2 NEFL42 / 50 / 60 / 74 / 100 CHD 30
11.0 troubleshooting 31
12.0 warranty 33
The information throughout this manual is believed to be correct at the time of printing. Wolf Steel Ltd. reserves
the right to change or modify any information within this manual at any time without notice. Changes, other than
editorial, are denoted by a vertical line in the margin.
note:

Napoleon ALLURAVISION Series Specifications

General

Control	Remote Control
Fuel Type	Electric
Installation Options	Wall Mount, Recessed
Flame Colors	Multi-Color
Lighting	LED lighting
Size Options	50", 60", 74", 100"
Vent Type	Vent Free
BTU	Up to 9, 000 BTU
