52
W415-1232 / B / 05.15.14
EN
13
16
17
11
12
2
10
5
4
18
1
6
8
9
19
13
15
16
11
12
2
10
6
5
17
1
7
8
9
18
ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED
02.21.14
MILLIVOLT VALVE TRAIN ASSEMBLY (W010-3175)
REF. NO. PART NUMBER DESCRIPTION
1 W100-0157 BURNER
2 W035-0326 VALVE TRAIN BASE
3
4
5
6
7
8 W725-0025 VALVE (NG)
9 W725-0043 VALVE (LP)
REF. NO. PART NUMBER DESCRIPTION
W010-0798 PILOT ASSEMBLY (NG)
W010-0799 PILOT ASSEMBLY (LP)
W290-0029 PILOT GASKET
W080-1402 VALVE BRACKET
2
1
4
3
W290-0235 VENTURI HOUSING GASKET
W350-0696 VENTURI HOUSING
W445-0021
TUBE/PIPE FITTING
W080-1339 IGNITER BRACKET
W357-0001 PUSH BUTTON IGNITER
W456-0054
BURNER ORIFICE #54 (LP)
W432-0078 MANIFOLD FLEX
W456-0042 BURNER ORIFICE #42 (NG)
12
13
14
15
16
17
18
11
214
10 W450-0036 NUT
W750-0193 WIRE ASSEMBLY
17.0 B42 MILLIVOLT VALVE TRAIN ASSEMBLY (W010-3175)
