17
www.napoleongrills.com
Propane Only
4 x N570-0080 (#14 x 1/2”)
3/8”(10mm)
3. Propane Tank Ring Installaon
Insert propane tank ring into slots in boom of shelf as shown. Fold tabs over to secure in place.
4. Le and Right Cart Panel Installaon
Install end cart panels ensuring slots in panel are to the top, rest panel on boom shelf and line up holes. Fasten using
(4) #14 x 1/2” screws.
To Next Page
