Bushing
2 x N160-0022 (pivot pin clip)
2 x N105-0011 (door bushing)
1
2
15. Door Installaon
First direct the pivot pin into the hole in the underside of the front cabinet support and then lower the door into the
bushing in the boom shelf. Once secure, snap the top pivot pin clip over the top pivot pin as illustrated.
