28
www.napoleongrills.com
17. Sear Plate Installaon
Insert sear plates into base, posion one over each tube burner with slots down to allow drippings to travel through.
18. Grids and Warming Rack Installaon
Posion grids and warming rack into base as shown. Rest warming rack on brackets inside hood and grids on front and back
lip of base.
16. Condiment Basket Installaon
Rotate basket slightly to allow wire to enter the holes in the side panel. Push through and upwards, rotang to allow the
bend in the wire to pass through the holes. Lay basket at against the side panel.
19. Grease Tray and Holder Installaon
Clip the wire grease tray holder into the two holes located in the center of the back panel. Place the aluminum grease tray
into the grease tray holder.
