NARDA ELT-400 - Page 58

7 Remote control ELT-400
7-12
SET:MODE<SP><param>[CR]<LF>
SET:MODE?[CR]<LF>
Response:
<param><CR><LF>
Meaning:
Selects the operating MODE. The operating modes are numbered
consecutively (1 to 4). The mode assigned to each number depends on the
instrument version.
Note: The operating mode selected can also be queried as text
information.
ª Remote control command GET:MODE_INFO?, see page 7-8
param Explanation
1 Displays the first operating mode counting from the left hand
side of the display.
ª LCD display elements, see page 4-3
2, 3, 4 Displays the second, third or fourth operating mode counting
from the left hand side of the display.
Table 7-9 Operating mode settings
