Instead, it is necessary to install overcurrent and short-circuit protection devices, such as fuses and circuit break-
ers, upstream of the device. These trigger in the event of failure of a component inside the device.
Supply voltage Model Recommended fuse
gC
Recommended circuit breaker
1 x 230 VAC V209 20 ABB MCB S201-C20
1 x 230 VAC V214 25 ABB MCB S201-C25
1 x 230 VAC V218 40 ABB MCB S201-C40
1 x 230 VAC V225 63 ABB MCBS201-C63
3 x 230 VAC V306 10 ABB MCB S203-C10
3 x 230 VAC V309 16 ABB MCB S203-C16
3 x 230 VAC V314 20 ABB MCBS203-C20
3 x 230 VAC V318 25 ABB MCB S203-C25
3 x 230 VAC V325 30 ABB MCB S203-C32
3 x 230 VAC V330 35 ABB MCB S203-C40
3 x 230 VAC V338 50 ABB MCB S203-C50
3 x 230 VAC V348 63 ABB MCB S203-C63
3 x 230 VAC V365 80 ABB MCB S203-C80
3 x 230 VAC V375 100 ABB MCB S203-C100
3 x 230 VAC V385 100 ABB MCB S203-C100
3 x 230 VAC V3118 160 SACE FORMULA 160
3 x 230 VAC V3158 200 SACE FORMULA 200
3 x 230 VAC V3185 200 SACE FORMULA 200
3 x 230 VAC V3215 250 SACE FORMULA 250
3 x 230 VAC V3268 315 SACE FORMULA 320
3 x 380 - 460 VAC V406 10 ABB MCBS203-C10
3 x 380 - 460 VAC V409 16 ABB MCBS203-C16
3 x 380 - 460 VAC V414 20 ABB MCBS203-C20
3 x 380 - 460 VAC V418 25 ABB MCBS203-C25
3 x 380 - 460 VAC V425 30 ABB MCBS203-C32
3 x 380 - 460 VAC V430 35 ABB MCBS203-C40
3 x 380 - 460 VAC V438 50 ABB MCBS203-C50
3 x 380 - 460 VAC V448 63 ABB MCBS203-C63
3 x 380 - 460 VAC V465 80 ABB MCBS203-C80
3 x 380 - 460 VAC V475 100 ABB MCBS203-C100
3 x 380 - 460 VAC V485 100 ABB MCBS203-C100
3 x 380 - 460 VAC V4118 160 SACE FORMULA 160
3 x 380 - 460 VAC V4158 200 SACE FORMULA 200
3 x 380 - 460 VAC V4185 200 SACE FORMULA 200
3 x 380 - 460 VAC V4215 250 SACE FORMULA 250
3 x 380 - 460 VAC V4268 315 SACE FORMULA 320
Residual Current Devices (RCD)
For inverter devices with single-phase power supply, use AC-sensitive RCD devices of both sine and pulse types.
The devices listed are, in order of priority:
• type F, marked with the symbols capable of detecting high-frequency currents up to 1 kHz.
• type A-APR, marked with the symbols
characterized by a slight intervention delay.
• type A, marked with the symbols
For inverter devices with three-phase power supply,use RCD devices that are sensitive to both alternating and
direct current. The following are suitable devices:
• Type B, marked with the symbols
VASCO - VAriable Speed COntroller
21
