Parameter Description
cosphi = X.XX The cosphi parameter represents the cosine of the phi phase displacement angle between voltage
and current. It is also called power factor.
P = XXXXX [W] Provides an estimate of the active electrical power absorbed by the motor.
STATUS: NORMAL In the absence of alarms, the STATUS is NORMAL.
Otherwise, the alarm message flashes and an intermittent acoustic signal is emitted which can be
silenced by pressing the STOP key.
Press th ENTER key to access the Diagnostics menu.
To return to the initial display, simply press the ENTER key.
MENU'
ENT to access
Press the ENTER key to access the menu display.
9.5.2. Diagnostics
Parameter Description
Inverter life
XXXXX h : XX m
Inverter life
Motor life
XXXXX h : XX m
Motor life
%f 25 50 75 100
%h XX XX XX XX
Operation statistics based on frequency and hours.
ALL. XXXXXXXXXXXXX
XXXXXXX h : XX m
Alarm log (up to 8) in relation to the life of the inverter
9.6. Menu
To access the Menu section, press the ENTER key on the MENU' / ENT to access screen.
To exit the Menu section, press the STOP key several times until you go back to the Initial View.
NOTE
Stop the motor before entering the Menu section.
Access to the menus is password-protected at two levels:
• Installer level: Allows editing the parameters related to pump operation in the hydraulic system on which it is
installed. Password 1, default 001.
• Advanced level: Allows editing the parameters that so critical that they may compromise the life of the device,
the pump, and the system if they are set incorrectly. Password 2, default 002.
Within each menu, it is possible to change the relative access password.
NOTE
When an incorrect password is entered to access both the installer and advanced level, the parame-
ters can only be displayed but not edited.
In case of loss of the password, contact the technical support service to obtain the universal pass-
word.
Menu Description Level Default
password
Control. param. Menu of parameters for controlling the pump in the hydraulic system in
which it is installed.
Installer 001
Motor parameters Menu of parameters for motor control Advanced 002
IN/OUT paramet. Menu of parameters for analog and digital inputs and outputs Installer 001
Connect. param. Menu of parameters for connectivity and external communication. Installer 001
Change init.set Initial configuration menu. Advanced 002
VASCO - VAriable Speed COntroller
37
