Nastec ANDO VASCO - Control Connections

V3158 , V3185 , V3215 , V3268 , V4158 , V4185 , V4215 , V4268
L1 L2 L3
P.E. U V W P.E.
LINE
MOTOR
L1 L2 L3
P.E. U V W P.E.
LINE
MOTOR
A [mm] Pre-insulated cable lug Stripping diagram
Power Supply
LINE
L1 360 Eyelet for M10 screw
A
L2 360 Eyelet for M10 screw
L3 360 Eyelet for M10 screw
P.E.
360 Eyelet for M10 screw
Motor
MOTOR
U 360 Eyelet for M10 screw
V 360 Eyelet for M10 screw
W 360 Eyelet for M10 screw
P.E.
360 Eyelet for M10 screw
7.5.2. Control connections
The control board is common for all models.
