Nastec ANDO VASCO - Dimensions and Weight; Cables Entry

Protection rating IP55 (NEMA 4)
IP54 (NEMA 12) sizes 3 & 4
Resistance to vibrations EN60068-2-6:2008, EN60068-2-27:2009, EN60068-2-64:2008,
WARNING
Protect the device from direct exposure to weather and sunlight.
5.3. Dimensions and weight
410 mm
260 mm
181 mm
228 mm181 mm
490 mm
260 mm
180 mm260 mm
680 mm
880 mm
380 mm
Size Maximum weight [kg]
1 5
2 9
3 40
4 80
5.4. Cables entry
Cable
gland
Tightening torque
[Nm]
Cable diameter
[mm]
Size
1
Size
2
Size
3
V3118 ,
V4118
Size
4
V3215 , V3268 ,
V4215 , V4268
M12 1,5 3,5-7 3 - 9 9 9 9
M16 3 5-10 - 4 - - - -
M20 6 7-13 2 - - - - -
M25 8 10-17 - 2 - - - -
M40 13 19 -28 - - 2 - - -
M50 15 27 -35 - - - 2 - -
M63 16 34 -45 - - - - 2 -
VASCO - VAriable Speed COntroller
13
