7.3. Connecting cables
WARNING
The connecting cables must comply with local regulations, feature the appropriate cross-section, and
meet the requirements for voltage, current, and temperature.
7.3.1. Power cables
Model Maximum cross-
section of the input
cable with ground
Maximum cross-
section of the output
cable with ground
Cable tightening
torque [Nm]
Ground cable
tightening torque
V209 3 x 2,5 mm
2
4 x 2,5 mm
2
1 1
V214 3 x 2,5 mm
2
4 x 2,5 mm
2
1 1
V218 3 x 6 mm
2
4 x 6 mm
2
1 3
V225 3 x 6 mm
2
4 x 6 mm
2
1,5 3
V306 4 x 2,5 mm
2
4 x 2,5 mm
2
1 1
V309 4 x 2,5 mm
2
4 x 2,5 mm
2
1 1
V314 4 x 6 mm
2
4 x 6 mm
2
1 3
V318 4 x 6 mm
2
4 x 6 mm
2
1 3
V325 4 x 6 mm
2
4 x 6 mm
2
1,5 3
V330 4 x 6 mm
2
4 x 6 mm
2
1,5 3
V338 4 x 16 mm
2
4 x 16 mm
2
3 3
V348 4 x 16 mm
2
4 x 16 mm
2
3 3
V365 4 x 35 mm
2
4 x 35 mm
2
4 4
V375 4 x 35 mm
2
4 x 35 mm
2
4 4
V385 4 x 35 mm
2
4 x 35 mm
2
4 4
V3118 4 x 35 mm
2
4 x 35 mm
2
4 4
V3158 4 x 50 mm
2
4 x 50 mm
2
20 20
V3185 4 x 50 mm
2
4 x 50 mm
2
20 20
V3215 4 x 95 mm
2
4 x 95 mm
2
20 20
V3268 4 x 95 mm
2
4 x 95 mm
2
20 20
V406 4 x 2,5 mm
2
4 x 2,5 mm
2
1 1
V409 4 x 2,5 mm
2
4 x 2,5 mm
2
1 1
V414 4 x 6 mm
2
4 x 6 mm
2
1 3
V418 4 x 6 mm
2
4 x 6 mm
2
1 3
V425 4 x 6 mm
2
4 x 6 mm
2
1,5 3
V430 4 x 6 mm
2
4 x 6 mm
2
1,5 3
V438 4 x 16 mm
2
4 x 16 mm
2
3 3
V448 4 x 16 mm
2
4 x 16 mm
2
3 3
V465 4 x 35 mm
2
4 x 35 mm
2
4 4
V475 4 x 35 mm
2
4 x 35 mm
2
4 4
V485 4 x 35 mm
2
4 x 35 mm
2
4 4
V4118 4 x 35 mm
2
4 x 35 mm
2
4 4
V4158 4 x 50 mm
2
4 x 50 mm
2
20 20
V4185 4 x 50 mm
2
4 x 50 mm
2
20 20
V4215 4 x 95 mm
2
4 x 95 mm
2
20 20
V4268 4 x 95 mm
2
4 x 95 mm
2
20 20
WARNING
Use unshielded cables for input cables and shielded cables for output cables.
WARNING
Always use cables with appropriate cable lugs, which may be supplied with the product.
