Nastec MIDA 207 - Power Connections: MIDA 304-409

MIDA 304 , MIDA 306 , MIDA 309 ,MIDA 404 , MIDA 406 , MIDA 409
MOTOR
U
V
W
LINE
L3
L2
L1
EMC
F+ F-
AN1
AN2
AN3
AN4
+15
0V
+10
0V
IN1
IN2
IN3
IN4
COMBO
MODBUS
STATUS
ALARM
G S2+ S2-
G S1+ S1-
NO1 COM1 NC1
NO2 COM2 NC2
A [mm] Pre-insulated cable lug Stripping diagram
Power Supply
LINE
L1 70 6.3 x 0.8 mm female Faston
A
L2 70 6.3 x 0.8 mm female Faston
L3 70 6.3 x 0.8 mm female Faston
P.E.
70 6.3 x 0.8 mm female Faston
Motor
MOTOR
U
120
(200)
6.3 x 0.8 mm female Faston
Wall installation
A
Installation on board the engine
(A)
V
120
(200)
6.3 x 0.8 mm female Faston
W
120
(200)
6.3 x 0.8 mm female Faston
P.E.
180
(200)
6.3 x 0.8 mm female Faston
MIDA
24
