Nastec MIDA 207 - Power Connections: MIDA 314-418

MIDA 314 , MIDA 318,MIDA 414 , MIDA 418
LINE
U V W
MOTOR
EMCEMC
DC IN/DC IN/
BRAKEBRAKE
DC -DC -
R -R -
R +R +
DC +DC +
L1 L2 L3
LINE
U V W
MOTOR
EMCEMC
DC IN/DC IN/
BRAKEBRAKE
DC -DC -
R -R -
R +R +
DC +DC +
L1 L2 L3
A [mm] Pre-insulated cable lug Stripping diagram
Power Supply
LINE
L1
180
(120)
Fork for M4 screw
Wall installation (through lower cable glands)
A
Installation on motor (through lateral cable
glands)
(A)
L2
180
(120)
Fork for M4 screw
L3
180
(120)
Fork for M4 screw
P.E.
180
(120)
Eyelet for M4 screw
Motor
MOTOR
U
180
(180)
Fork for M4 screw
Wall installation
A
Installation on board the engine
(A)
V
180
(180)
Fork for M4 screw
W
180
(180)
Fork for M4 screw
P.E.
180
(180)
Eyelet for M4 screw
MIDA
25
