Nastec VASCO - Advanced Parameters

21
parameter
default
desciption
Constant press.
Fix speed
Const.press.2val
Fix speed 2 val.
External speed
Constant temp.
Constant flow
--->
If, during the test, the motor runs in reverse, it is
possible to change the wiring sequence via
software without physically changing wires at the
terminals.







N.O.
By selecting N.A. (normally open) VASCO runs
the motor if the digital input 1 is open; motor will
be stopped if the digital input 1 is closed.
By selecting N.C. (normally closed) VASCO runs
the motor if the digital input 1 is closed; motor
will be stopped if the digital input 1 is opened.







N.O.
By selecting N.A. (normally open) VASCO runs
the motor if the digital input 2 is open; motor will
be stopped if the digital input 2 is closed.
By selecting N.C. (normally closed) VASCO runs
the motor if the digital input 2 is closed; motor
will be stopped if the digital input 2 is opened.







N.O.
By selecting N.A. (normally open) VASCO runs
the motor if the digital input 3 is open; motor will
be stopped if the digital input 3 is closed.
By selecting N.C. (normally closed) VASCO runs
the motor if the digital input 3 is closed; motor
will be stopped if the digital input 3 is opened.







N.O.
By selecting N.A. (normally open) VASCO runs
the motor if the digital input 4 is open; motor will
be stopped if the digital input 4 is closed.
By selecting N.C. (normally closed) VASCO runs
the motor if the digital input 4 is closed; motor
will be stopped if the digital input 4 is opened.







1
Digital input IN2 and IN3 delay.
Digital input IN1 and IN4 have 1 second fix delay.







Pressing ENT allows the installer level password
(1st level) (default 001) to be changed.







6.6 Advanced parameters
All the advanced parameters, due to their importance, are already set during initial setup (cap. 6.2 Initial Configuration).
However, it is always possible to modify individual parameters or modify the password 2:
Parameters
Default
Description
XXX
Motor rated voltage (as shown in the motor plate)
Average voltage drop due to the inverter is between 20 V and 30 Vrms
based on load condition.
1%
Refers to the voltage increase during the start up of the motor.
Warning: An excessive value can seriously damage the motor. Contact the
motor manufacturer for further information.
If a single-phase motor is used, a value of 1% is suggested to increase the
Voltage boost
V = XX [%]
Rated motor Volt.
V = XXX [V]
Change PASSWORD1
ENT
Dig.In.2/3 delay
t= XX [s]
Digital input 4
N.O. / N.C.
Digital input 3
N.O. / N.C.
Digital input 2
N.O. / N.C.
Digital input 1
N.O. / N.C.
Rotation sense
---> / <---
