National Instruments NI PXI-4060 User Manual

NI Digital Multimeters Getting Started Guide 28 ni.com
(NI PCI-4060)
1. Remove all front panel connections from the NI PCI-4060.
2. Power off the computer, and remove the device.
3. Remove the four screws that secure the top and bottom insulators onto the device, as shown in
Figure 23.
Figure 23. Removing the Insulators from the NI PCI-4060
4. Remove the top and bottom insulators.
1 Screws Securing Insulators 2 Insulators
2
2
1
1
1 1

National Instruments NI PXI-4060 Specifications

General

Brand	National Instruments
Model	NI PXI-4060
Category	Multimeter
Language	English
