National Instruments NI PXIe-1085 User Manual

Appendix B Pinouts B-4 | ni.com
System Timing Slot Pinouts
Table B-5. TP1 Connector Pinout for the System Timing Slot
Pin A B ab C D cd E F ef
1 PXIe_DSTARA3+ PXIe_DSTARA3- GND NC NC GND NC NC GND
2 PXIe_DSTARC4+ PXIe_DSTARC4- GND PXI_STAR12 PXI_STAR13 GND NC NC GND
3 PXIe_DSTARB4+ PXIe_DSTARB4- GND NC NC GND NC NC GND
4 PXIe_DSTARA4+ PXIe_DSTARA4- GND NC NC GND NC NC GND
5 PXIe_DSTARC5+ PXIe_DSTARC5- GND PXI_STAR14 PXI_STAR15 GND NC NC GND
6 PXIe_DSTARB5+ PXIe_DSTARB5- GND NC NC GND NC NC GND
7 PXIe_DSTARA5+ PXIe_DSTARA5- GND NC NC GND NC NC GND
8 PXIe_DSTARC6+ PXIe_DSTARC6- GND PXI_STAR16 RSV GND NC NC GND
9 PXIe_DSTARB6+ PXIe_DSTARB6- GND NC NC GND NC NC GND
10 PXIe_DSTARA6+ PXIe_DSTARA6- GND NC NC GND NC NC GND
