Chapter 9 Counters
NI USB-621x User Manual 9-30 ni.com
CTR 0 B 2 (PFI 1)
CTR 1 SRC 4 (PFI 3)
CTR 1 GATE 3 (PFI 2)
CTR 1 AUX 4 (PFI 3)
CTR 1 OUT 7 (PFI 5)
CTR 1 A 4 (PFI 3)
CTR 1 Z 2 (PFI 1)
CTR 1 B 3 (PFI 2)
FREQ OUT 8 (PFI 6)
Table 9-6. Default NI-DAQmx Counter/Timer Pins for USB-6218 Devices
Counter/Timer Signal Default Terminal Number (Name)
CTR 0 SRC 1 (PFI 0)
CTR 0 GATE 2 (PFI 1)
CTR 0 AUX 34 (PFI 9)
CTR 0 OUT 6 (PFI 4)
CTR 0 A 1 (PFI 0)
CTR 0 Z 2 (PFI 1)
CTR 0 B 34 (PFI 9)
CTR 1 SRC 4 (PFI 3)
CTR 1 GATE 3 (PFI 2)
CTR 1 AUX 35 (PFI 10)
CTR 1 OUT 7 (PFI 5)
CTR 1 A 4 (PFI 3)
CTR 1 Z 3 (PFI 2)
CTR 1 B 35 (PFI 10)
FREQ OUT 8 (PFI 6)
Table 9-5. Default NI-DAQmx Counter/Timer Pins for USB-6210/6211/6215 Devices (Continued)
Counter/Timer Signal Default Terminal Number (Name)
