1-2 | ni.com
Chapter 1 Introduction
PXIe-8840
Description
The PXIe-8840 PXI Express/CompactPCI Express embedded controller is a high-performance
PXI Express/CompactPCI Express-compatible system controller. The PXIe-8840 controller
integrates standard I/O features in a single unit by using state-of-the-art packaging. Combining
a PXIe-8840 embedded controller with a PXI Express-compatible chassis, such as the
PXIe-1082, results in a fully PC-compatible computer in a compact, rugged package.
The PXIe-8840 has an Intel
®
Core
™
i5 4400E processor (2.7 GHz dual core processor), all the
standard I/O, and a 250 GB (or larger) hard drive. It also has a PCI-based GPIB controller and
an ExpressCard/34 expansion slot.
1
The standard I/O on each module includes two DisplayPort video, one RS-232 serial port, four
Hi-Speed USB ports, two SuperSpeed USB ports, two Gigabit Ethernet, a reset button, and a PXI
trigger.
Functional Overview
This section contains functional descriptions of each major logic block on the PXIe-8840
embedded computer.
1
Available on the PXIe-8840 ExpressCard variant only.
