National Instruments PXIe-8840 User Manual

3-2 | ni.com
Chapter 3 I/0 Information
Front Panel
Figure 3-1 shows the front panel layout and dimensions of the PXIe-8840. Dimensions are in
inches (millimeters).
Figure 3-1. PXIe-8840 Front Panel Layout and Dimensions
1.064 in. (27.02 mm)
1.573 in. (39.95 mm)
2.345 in. (59.56 mm)
3.087 in. (78.41 mm)
3.554 in. (90.27 mm)
4.393 in. (111.58 mm)
0.000 in. (0.00 mm)
1.948 in. (49.47 mm)
3.289 in. (83.54 mm)
3.750 in. (95.25 mm)
1.185 in. (30.10 mm)
2.814 in. (71.48 mm)
1.970 in. (50.04 mm) 2.850 in. (72.39 mm)
0.500 in. (12.70 mm)
1.636 in. (41.55 mm) 1.301 in. (33.05 mm)
2.306 in. (58.57 mm)
0.00 in. (0.00 mm)
2.259 in. (57.38 mm)
0.996 in. (25.29 mm)
1.497 in. (38.02 mm)
2.189 in. (55.59 mm)
2.332 in. (59.22 mm)
0.852 in. (21.65 mm)
