© National Instruments | 2-15
PXIe-8840 User Manual
Figure 2-3. Clearing the CMOS Contents
LabVIEW RT Installation
This section explains software installation and switch configuration for LabVIEW RT on your
PXI Express controller.
LabVIEW RT Software Installation
The following section describes the necessary steps to get your PXI Express embedded
controller setup to run LabVIEW Real-Time. In this section you will configure the boot mode
of the controller, verify or change IP settings, and install LabVIEW Real-Time software.
Complete the following steps to install the LabVIEW RT software.
1. Boot the NI PXI Express embedded controller into the real-time operating system. Refer to
the LabVIEW RT Configuration Switches section or the LabVIEW RT Setup Menu section
in this manual to configure the controller for booting into LabVIEW RT.
1 Push-Button Switch SW1
1
