Chapter 2 Installation and Configuration
– Interrupt Request (IRQ)—This item displays the interrupt request (IRQ) for the
onboard serial port.
LabVIEW RT Setup Menu
Use this menu to configure boot options for LabVIEW RT if it is installed on the controller. If
you are not using LabVIEW RT, you should leave these settings at default.
Note The settings below override the behavior of the switches shown in Figure 2-4.
Refer to the LabVIEW RT Configuration Switches section for more information. To
use the settings from the switches, select Use Switch Setting for each option.
• Boot Configuration—This setting selects whether the controller should boot
LabVIEW RT, LabVIEW RT Safe Mode, or an installed OS such as Windows 7. The
default is Use Switch Setting.
• Reset IP Address—If the controller is deployed to a different subnet from which it was
originally configured, or if the current IP address is invalid, use this switch to reset the IP
address and other TCP/IP settings to their factory defaults during LabVIEW RT startup.
The default is Use Switch Setting.
Note By default, the target automatically attempts to connect to the network using
DHCP. If the target is unable to initiate a DHCP connection, the target connects to the
network with a link-local IP address or 169.254.x.x.
• Disable Startup VI—If the controller becomes inaccessible because of a startup VI, this
switch can prevent VIs from automatically running at startup. The default is Use Switch
Setting.
Current Hardware Switch Settings
This submenu displays the current values of the LabVIEW RT configuration switches,
indicating Boot Configuration, Reset IP Address, and Disable Startup VI switch status.
• LabVIEW RT Configuration Overrides—Use this setting to access the LabVIEW RT
Configuration Overrides submenu. Refer to the LabVIEW RT Configuration Overrides
Submenu section for more information.
LabVIEW RT Configuration Overrides Submenu
To minimize jitter when booting into LabVIEW Real-Time mode, the following features are
automatically disabled. You can manually enable these features. Refer to the CPU
Configuration Submenu for specific details on what each feature enables.
• CPU Hyper Threading—The default is Use RT Default.
• CPU C-States—The default is Use RT Default.
