© National Instruments | A-1
A
Specifications
This appendix lists the electrical, mechanical, and environmental specifications of the
PXIe-8840 embedded controller.
Features
PXIe-8840
CPU Intel
®
Core
™
i5 4400E (2.70 GHz dual core processor)
On-die L2 cache 3 MB
Single-Channel 1600 MHz
DDR3L RAM, PC3 12800
4 GB Standard
8 GB Maximum
Hard Drive 250 GB Serial ATA, minimum
*
Ethernet Two 10/100/1000 BaseT ports
PXI Express 4 Link Configuration x4, x4, x4, x4
PXI Express 2 Link Configuration x8, x8
GPIB (IEEE 488 Controller) Yes
Serial Ports (RS-232) Ye s (1)
Parallel Port No
Hi-Speed USB (2.0) Ports Yes (4 )
SuperSpeed USB (3.0) Ports Yes (2 )
ExpressCard/34 Slot (available on
the PXIe-8840 Duo-Core
ExpressCard variant only)
Yes
PS/2 Keyboard/Mouse Connector No
PXI Trigger Bus Input/Output Yes
Installed Operating System Windows 7 Professional
*
Extended-temperature 24/7 option provides 80 GB minimum SATA solid-state drive.
