Page #23 background imageLoading...
Page #23 background image
Table 8. CAN Port Accessories
Accessory Part Number
NI Single-Board RIO 10-pin header to 9-pin D-SUB 153158-10
DIO Port
The sbRIO-9637 has an DIO port for input and output configurations.
The following figure shows the pinout for the DIO port.
Figure 18. DIO Port Pinout
DIO4
DIO5
DIO6
DIO7
DIO8
DIO9
DIO10
DIO11
DIO12
DIO13
DIO14
DIO15
DIO16
DIO17
DIO18
DIO19
DIO20
DIO21
DIO22
DIO23
DIO24
DIO25
DIO26
DIO27
5 V
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
5 V
5049
4847
4645
4443
4241
4039
3837
3635
3433
3231
3029
2827
2625
2423
2221
2019
1817
1615
1413
1211
109
87
65
43
21
Pin 1
Pin 50
MIO Port
The sbRIO-9637 has an MIO port for input and output configurations.
The following figure shows the pinout for the MIO port.
22 | ni.com | NI sbRIO-9637 User Manual
