National Instruments sbRIO-9637 User Manual

Figure 19. MIO Port Pinout
AI0
AGND
AI1
AI2
AGND
AI3
AI4
AGND
AI5
AI6
AGND
AI7
AGND
AO0
AO1
AO2
AO3
NC
NC
NC
NC
DIO0
DIO1
DIO2
DIO3
AGND
AI9
AGND
AI11
AGND
AI12
AI13
AI8
AI10
AGND
AI14
AI15
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
DGND
DGND
DGND
DGND
5049
4847
4645
4443
4241
4039
3837
3635
3433
3231
3029
2827
2625
2423
2221
2019
1817
1615
1413
1211
109
87
65
43
21
Pin 1
Pin 50
USB Host Ports
The USB host ports on the sbRIO-9637 support common USB mass-storage devices such as
USB Flash drives and USB-to-IDE adapters formatted with FAT16 and FAT32 file systems.
The sbRIO-9637 USB host port supports Web cameras that conform to the USB Video Device
Class (UVC) protocol as well as machine vision cameras that conform to the USB3 Vision
standard and are USB 2.0-compatible.
Caution Do not hot-swap USB devices while the sbRIO-9637 is in a hazardous
location or connected to high voltages. If the sbRIO-9637 is not in a hazardous
location, you can connect and disconnect USB devices without affecting operation.
The sbRIO-9637 provides a multi-function bracket that can be used in conjunction with a
1 mm (0.039 in.) thick front panel and a 6.35 mm (0.250 in.) length 4-40 M-F standoff to
provide retention for the USB connector. The following table shows the pinout for the USB
host ports.
NI sbRIO-9637 User Manual | © National Instruments | 23
