= 80 %
5
and
= 90 %
= 50%
Note You must add 10% to the calculated or measured total power requirement to
account for transient and startup conditions.
Table 18. Approximate Maximum Power Requirement
Power Values and Calculations
Maximum P
int
11.08 W
Maximum P
DIO
Total DIO current × 3.3 /0.8
Maximum P
5V
Total 5 V current × 5 /0.9
Maximum P
USB
Total USB current × 5 /0.9
Maximum P
SD
1
Total SD current × 3.3 /0.8
Maximum P
AO
Total AO current × 15 /0.5
Note These calculations are intended to approximate the maximum power
requirements for an NI sbRIO device system. For a more accurate estimate of the
power consumption of a specific application, NI recommends that you directly
measure a board running the application in an environment representative of the
intended use case.
Configuring the sbRIO-9637
You can connect the sbRIO-9637 to a host computer or network and configure the startup
options using the RJ-45 Gigabit Ethernet port.
Tip Refer to the NI sbRIO-9637 Getting Started Guide on ni.com/manuals for basic
configuration instructions and information about connecting to a host computer
using the RJ-45 Gigabit Ethernet port.
1
The SD specification allows 200 mA maximum current draw for an SD card. If your SD card does
not specify maximum current draw, assume 200 mA.
NI sbRIO-9637 User Manual | © National Instruments | 39
