National Instruments SCXI-1000 - Chapter 3 Configuring Your SCXI Hardware and Software; Module Configuration; Figure 3-1. Removing the SCXI Module Grounding Screw

© National Instruments Corporation 3-1 Getting Started with SCXI
3
Configuring Your SCXI Hardware
and Software
This chapter explains how to configure your SCXI hardware and National
Instruments software.
Module Configuration
You may need to configure your SCXI modules before using them in your
application. Some SCXI modules have a number of user-configurable
jumpers that you can access by removing a single screw on the back of the
module, as shown in Figure 3-1.
Figure 3-1. Removing the SCXI Module Grounding Screw
Rear of Module
Grounding Screw
