Nautilus E618 - Hardware; Tools

9
Item Qty Description Item Qty Description
A6%XWWRQ+HDG+H[6FUHZ0[ZLWK
Thread Lock)
F 6 Wave Washer
B 4 Serrated Washer, M8 G 8 Lock Washer, M8
C 8 Wide Washer, M8 H 2 Pivot Sleeve
D4%XWWRQ+HDG+H[6FUHZ0[ I53KLOOLSV+HDG6HOIWDS6FUHZ0[
E2+H[+HDG6FUHZ0[ J43KLOOLSV+HDG6FUHZ0[
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remain-
ing Hardware after the proper assembly of your machine.
HARDWARE / TOOLS
Tools
Included
6 mm
AB C D E F
GH
I
J
#2
13 mm
15 mm
19 mm
