Nautilus E626 Service Manual

25
4. Thread the Crank Puller into the Crank Arm (B). When the Crank
Puller is in the correct position, only 1-2 threads on the outer portion (CP2)
of the Crank Puller should show.
Note: Be sure the end of the Bolt (CP1) of the Crank Puller is ush
with the Nut (CP2) as shown, before use.
5. Using a wrench, turn the inner portion (CP3) of the Crank Puller
clockwise. The Crank Arm (B) will slide off as it is tightened.
CP1 CP2 CP3
B
CP2
CP3

Nautilus E626 Specifications

General

Bottle holder	Yes
Product color	Black, Grey
Number of programs	29
Maximum user weight	136 kg
Number of resistors	25
Training displayed parameters	Calories, Distance, Time
