53
6. Installation is the reverse procedure. Tape the cardboard to the new
Brake Magnet. Be sure the cardboard will completely cover the new Brake
Magnet before installation.
NOTICE: Do not crimp the cables.
7. Before fully attaching the Shrouds, remove the cardboard from
between the Brake Magnet (A) and the Flywheel (B). Power up the
machine to verify that the Magnet Arm can move freely, and that the Brake
Magnet and Flywheel do not touch at the maximum resistance level.
Machine is on. Current is active. There is risk of electrical
shock.
If necessary, refer to the “Set the Brake Tension” procedure.
8. Final Inspection
Inspect your machine to ensure that all hardware is tight and components
are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
