Nautilus R618 - Replace the Console

20
Leveling the Machine
Levelers are found on each side of the Rear Stabilizer and on the Frame Rail. On the Rear Stabilizer, turn the stabilizer
foot to adjust.
Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or
damage to the machine can occur.
7RDGMXVWWKHOHYHOHURQWKH)UDPH5DLO
1. Loosen the upper locking nut.
2. Turn the leveler to adjust the height.
Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or
damage to the machine can occur.
3. Tighten the upper locking nut to lock the leveler.
0DNHVXUHWKHELNHLVOHYHODQGVWDEOHEHIRUH\RXH[HUFLVH
