6
SPECIFICATIONS
41.8” (104cm)
21.6” (55cm)
57.6” (146cm)
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on
a hard, level surface. Allow a workout area of a minimum 90´ [ 70´ 2.3m [ 1.8m.
Basic Assembly Tips
Follow these basic points when you assemble your machine
1. Read and understand the “Important Safety Instructions” before assembly.
2. Collect all the pieces necessary for each assembly step.
3. Using the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counter
clockwise) to loosen, unless instructed otherwise.
4. When attaching 2 pieces, gently lift and look through the bolt holes to help insert the bolt through the holes.
5. The assembly can require 2 people.
Maximum User Weight: 300 lbs. (13 kg)
Machine Weight: 8. lbs. (31.1 kg)
Power Requirements:
Operational 9oltage 99DC
Operating Current 1.5A
AC Power Adapter UL listed, Rated 10092409 50/0Hz
Input, 99DC, 1500mA Output. Class 2.
To Next Page
