SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES

WARNING

Topreventpersonalinjuryordeath,storediesel

fuelproperlyinanapprovedcontainerdesigned

forandclearlymarkedDIESELFUEL.

Figure28Fuellterheaderassembly

1.Electricfuelpump

2.Fuelltercover

3.ExhaustGasRecirculation(EGR)valve

4.Oillltube

5.Waterdrainvalve

1.Ifnecessary,connectahosetotheendofthewaterdrain

valve.

2.Putasuitablecontainerunderwaterdrainvalveordrain

hose.

3.TurnignitionswitchtoON.Thiswillstarttheelectricfuel

pump.Donotstartengine.

NOTE:Thewater/fuelmixturewilldrainslowlyandmay

takeuptoaminutetoattainpurefuelow.

4.Turnwaterdrainvalvetoopenandallowwater/fuelmixture

todrain.Continuedraininguntilonlyfuelisdraining.

NOTE:Fuelwillonlydrainfromthewaterdrainvalveas

longastheelectricfuelpumpisrunning.Theelectric

fuelpumpcanrunfrom10to20seconds.Donotturnthe

ignitionswitchtoOFFthenONagainwithoutwaitingthe10

seconds.Ifthe10secondswaitingperiodisnotobserved,

theelectricfuelpumpwillnotrestart.

5.Fuelwillonlyowaslongasthefuelpumpisrunning.If

additionalfuelpumpruntimeisdesired,turntheignition

switchtoOFF,wait10secondsthenturntheignitionswitch

toONtocontinuedrainingwater.

6.Oncefuel-waterdrainingiscomplete,closewaterdrain

valveandturntheignitionswitchtoOFF.

7.Recycleordisposeofdraineduidsproperlyaccordingto

applicableregulations.
