Hardware Installation 2-63
Installing a Secondary Display (Dual Display)
The Motherboard uses an integrated video controller. This controller supports a Monitor
port (VGA) and a Digital Display port (DVI) on the motherboard connector row. These
two ports provide a single display mode (DVI or VGA) or a dual display mode (DVI and
VGA). Dual display mode can be a clone (same video data displayed on both displays) or
an extended desktop (the desktop spans across both displays).
The dual mode is configured using the Intel® Graphics Media Accelerator control panel.
1. Power down the system.
2. Connect the secondary display.
Note: Both displays must be connected to the 7610 before powering up the system.
3. Apply power to the system.
4. Right click the Desktop and then select Graphics Properties from the menu to start
the control panel. The following screen indicates the system was previously
configured with a single VGA display (Monitor).
