BIOS Setup 3-83

Chipset Menu

► PCH-IO Configuration

. ► PCI Express Configuration

. PCI Express Clock Gating [Enabled]

. DMI Link ASPM Control [Disabled]

. DMI Link Extended Synch Control [Disabled]

. PCIe-USB Glitch W/A [Disabled]

. Subtractive Decode [Disabled]

. ► PCI Express Root Port 1,2,4,5,6,7,8

. PCI Express Root Port 1,2,4,5,6,7,8 [Enabled]

. ASPM Support [Auto]

. . URR [Disabled]

. . FER [Disabled]

. . NFER [Disabled]

. . CER [Disabled]

. . CTO [Disabled]

. . SEFE [Disabled]

. . SENFE [Disabled]

. . SECE [Disabled]

. . PME SCI [Enabled]

. . Hot Plug [Disabled]

. PCIe Speed [Auto]

. Extra Bus Reserved 0

. Resreved Memory 10

. Reserved I/O 4

. ► USB Configuration

. EHCI1 [Enabled]

. EHCI2 [Enabled]

. USB Ports Per-Port Disable Control [Disabled]

. ► PCH Azalia Configuration

NCR 7601 User Manual
