NCR Orderman7 User Manual V01.04 Service station and multi service station
7.3 Overview of the multi service station
The multi service station is designed to charge up to five handhelds and up to five battery packs.
The service station and multi service station also provide an IP-based Ethernet connection to the
host system.
15: Multi service station
Charging contacts, handheld charging slot
Chargeing status LED
Fast-charging slot
Protective cover for charging contacts on the
quick-charging slot
Connection for Orderman power supply
2x RJ45 Ethernet network port*
* One of the two Ethernet ports can be used as a network connection for another Ethernet device.
Orderman GmbH (Part of NCR Corporation) 25
